BadAss™Center-Mount, Bolt-On, Self-closing Hinges

SKU# CI3860

Designed for gates where welding is not an option

• Heavy duty, bolt-on, self-closing gate hinge that is easy to install
• CNC machined to perfection for near frictionless movement
- Quiet and smooth operation
- Reduced wear on automatic gate systems
• Horizontally adjustable for precise installations
• No greasing or maintenance required on sealed bearings. EVER!
• Ideal for panic-bar installations
• Self-closing maximum gate weight: 440 lb (with 2 closers) 2 x CI3835
• Self-closing maximum gate weight: 300 lb (with a closer & plain hinge set CI3860)
• 5 tension-adjustment settings
• Tested to over 1 Million Open/Close cycles
• Limited Lifetime Warranty
• ADA suitable

BUY NOW CI3860

BUY NOW CI3835
The Bolt-On BadAss was designed to be used on gates where welding the hinges to the gate and the end post is not an option. Center-mount, bolt-on, self-closing gate hinges are easy to install and adjust for perfect installation. Compatible for use on aluminum gates for non-welding and high-traffic gates to ensure correct movement. Horizontally adjustable for perfect installations that ensures proper gate function.

Brand	Shut It® BadAss
Product Code	CI3860, CI3835
Gate Application	Pedestrian Gate, Driveway Gate - Double, Driveway Gate - Single, Pet Gate, Playground Gate, Public/Commercial Gate, Automated/Electric Gate, Security Gate, Privacy Gate
Gate Type	Self-Closing
Gate Material	Steel/Ornamental Iron, Aluminum
Approx Gate Size	6ft W x 8ft H (1.5m x 2m)
Gate Frame/Post Shape	Square-to-Square
Min Post Size	1½"+ (38mm)
Ideal Gate Gap	2.9"-3.4" (74-97mm)
Fixing Method	Bolt-On
Color/Finish	Zinc
